Acoustic Operable Partition with STC Rating 42-56dB and 6061-T6 Aluminum Alloy Frame for Superior Durability

ब्रांड नाम:	AE
मॉडल संख्या:	एई65
एमओक्यू:	10 वर्ग मीटर
कीमत:	USD 70-98Per Square Meter
भुगतान की शर्तें:	एल/सी, डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन, मनीग्राम
आपूर्ति करने की क्षमता:	1000 वर्ग मीटर प्रति माह

विस्तृत जानकारी

उत्पाद का वर्णन

विस्तृत जानकारी

उत्पत्ति के प्लेस:

गुआंग्डोंग, चीन

प्रमाणन:

ISO9001 SGS

उत्पाद:

ध्वनिक संचालन योग्य विभाजन

अनुपालन:

रेस्तरां, कार्यालय भवन

परिष्करण विकल्प:

68मिमी एमडीएफ बोर्ड

DIMENSIONS:

अनुकूलन (ऊंचाई: 4.5 मीटर तक, प्रति पैनल चौड़ाई: 1.2 मीटर तक)

डिज़ाइन:

OEM और ODM

एसटीसी रेटिंग:

42-56डीबी

पैकेजिंग विवरण:

प्लाईवुड केस या स्टील पैलेट के साथ फोम लेयर और हार्ड कार्डबोर्ड

प्रमुखता देना:

STC Rating 42-56dB Acoustic Operable Partition

6061-T6 Aluminum Alloy Frame Movable Partition Wall

Q235 Steel Frame Soundproof Partition Wall

उत्पाद का वर्णन

Acoustic Operable Partitions - Customizable Movable Partition Walls

Office Acoustic Operable Partition Wall System with wooden finish

Our cost-effective soundproof movable partition wall systems feature built-in passageway doors, providing both privacy and accessibility. These partitions create quiet, adaptable spaces while maintaining budget efficiency.

Key Features

AE65 series operable partition system with manually operable panels
Simple operation using the operating handle to lock panels in place
Activates top and bottom seals for effective acoustic barriers
No special tools required for installation or operation

Product Strengths

German Partition Technology Global Professional Space Solutions
Highly competitive pricing structure
Stringent quality control measures
Efficient communication channels
State-of-the-art technology products
Extensive experience with large-scale projects
Reliable delivery time management

Roller Options & Features

Dupont POM roller construction
304 stainless steel heavy duty roller with safety device & CNC machining
Patented wheel surface and shape design for smooth operation

Panel Options & Features

Available thicknesses: 68mm, 89mm, and 105mm
Wide selection of acoustical and decorative finishes
6061-T6 profile with Q235 steel frame for enhanced durability
Top & bottom jack lifting mechanism seal with 800N power
Magnetic seal in concave & convex profile with 40N/m magnetic attraction

Technical Specifications

Series	Element Thickness (mm)	Element Width (min/max mm)	Clear Height (min/max mm)	Construction	Panel Fixing	Element Interconnection
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
